Characteristic: designed for application on Ammonia or Acetylene measurement condition.
Dials Size: 1.5"(40mm), 2"(50mm), 2.5“(63mm), 4”(100mm) and 6“ (150mm)
Case: Stainless steel
Pressure range: 0 -250Mpa, other scale units bar, psi, kg/cm2 etc. optional
Movement: Brass/ Stainless steel
Socket: Brass/ Stainless steel
Bourdon tube: Phosphor Bronze/ Stainless steel
Dial plate and pointer: Aluminum
Window: Glass or Plastic
Connection threads: Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)
Mounting: Bottom, back and panel
Accuracy: 2.5%, 1.6%
