Nominal diameters: 60, 100, 150, 200 and 250 mm
Accuracy：60 mm (2.5%) and 100, 150, 200 and 250 mm (1.6%)
Measuring range: 60mm -0.1MPa～0…2.4MPa, 0～0.1…60MPa; 100&150mm -0.1MPa～0…2.4MPa,0～0.1…100MPa; 200&250mm 0～0.1…60MPa.
Working temperature: ambient temperature -25～70℃
Pressure measuring element: stainless steel
Case material: stainless Steel
Surface glass: double-layer safety explosion-proof glass
Dial: aluminum white surface, black scale
Pointer: aluminum, black
